| Total Energy (kWh) | 16.08 |
| Usable Energy (kWh) | 15.11 |
| Nominal Voltage (Vd.c) | 51.2 |
| Voltage Range (Vd.c) | 44.8-57.6 |
| Rated Capacity (Ah) | 314 |
| Max. Charge/Discharge Current | 200A / 200A |
| Recommend DOD | 90% |
| BMS Features | Over-voltage, Over-current, Short-circuit, Low-voltage, Over-temperature Protection & Cell Balance |
| Scalability | Max 20 in Parallel |
| Weight (KG) | 120 |
| Standard Features | Button-Controlled Screen, Trip Protection, Bluetooth, Water Proof (Optional) |
| Communication | CAN / RS485 |
| Operating Environment | Indoor (5%-95% RH, No Condensing) |
| Cycle Life | ≥8000 @ 25°C |
Reliable & Secure Transportation: We provide transparent and secure logistics for residential and industrial energy storage systems. From warehouse dispatch to final delivery, we prioritize professionalism to ensure equipment arrives safely.
Transparent Tracking: Real-time monitoring is available through dedicated tracking systems, covering every milestone from warehouse departure to last-mile delivery.
